NLT4MX-BAG
NEUTRIKSTX Series - 4 pole male cable connector - black-chrome metal housing - chuck type strain relief The speakON STX Series was especially designed for heavy duty amplifier-loudspeaker applications like professional touring. The extremely rugged and durable .. Ver descripción completa
Atributo del producto
Valor de atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
NEUTRIK
Nº de pieza:
NLT4MX-BAG
RoHS:
Yes
HTS:
8536694040
COO:
LI
ECCN:
EAR99
Paquete estándar del proveedor
50
Type:
Loudspeaker Connector
Gender:
M
Body Orientation:
Straight
Mounting:
Cable Mount
Housing Material:
Zinc Die Cast
Number of Contacts:
4
Contact Plating:
Silver
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C
Ciclo vital:
Terminado
4 pole male cable connector, black-chrome metal housing, chuck type strain relief
<br /><br />The new STX Series is the next generation of 4 pole speakON connectors especially designed for amplifier-loudspeaker applications in harsh and demanding environments such as professional touring. The extremely rugged and durable STX Series feature an all metal housing and a built-in gasket providing weatherproof protection to IP54. The 4 pole version is now available as 4 gender system including male cable and female chassis connector.
Características destacadas del producto:
- Current rating 40 Amp continuous, 50 Amp audio with 50% duty cycle
- Robust and durable all metal housing
- Sealing ring provides weatherproof IP54 rating
- Reinforced metal quick lock system for ease and precise locking
- Extra large solder contacts for up to 6mm² (AWG10) wires
- Mate with all available Speakon products
Palabras clave de búsqueda:
NLT4MXBAG
Este producto no está en stock y no se puede hacer un pedido pendiente
Posibles opciones de reemplazo disponibles. Ver Alternativas
