G6A-234P-ST-US-DC24 by omron electronics
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

G6A-234P-ST-US-DC24

Omron Electronics

Signal Relay 24VDC 2A DPDT(20.2x10.1x8.4)mm THT .. Ver descripción completa

Cumple con RoHS
Box embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Omron Electronics
Nº de pieza:
G6A-234P-ST-US-DC24
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
500
Tipo de paquete:
Box
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 70 °C
Dimension:
20.2 x 10.1 x 8.4 mm
Termination Style:
PC Pin
Coil Current:
8.3 mA
Contact Form:
2 Form C
The G6A-234P-ST-US-DC24 is a Non-latching Low Signal Relay with DC coil. This G6A-series signal relay has DPDT AgPd (Au clad) contacts. Low-profile design allows use in 12.7mm (0.5 inch) PC board rack. Surge withstand voltage meets FCC Part 68 regulation. Unique moving loop (permanent magnet) armature reduces relay size, magnetic interference and contact bounce time. High sensitivity can be driven by digital circuits Units can be mounted side by side due to low magnetic leakage Special models available for ultrasonic cleaning and low thermo electromotive force -40 to 70°C Operating temperature range Applications Industrial
Palabras clave de búsqueda:
G6A234PSTUSDC24
EN STOCK: 137
Puede enviar inmediatamente
Cantidad mínima de pedido:
5
Plazo de entrega de fábrica
4 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
5
$5.80
$29.00
50
$4.38
$219.00
100
$4.33
$433.00
250
$4.29
$1,072.50
500
$4.27
$2,135.00
1.000
$4.25
$4,250.00
2.500
$4.23
$10,575.00
5.000 +
$4.21
$21,050.00
