CB1F-24V by panasonic electronic components
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

CB1F-24V

Panasonic Electronic Components

Power Relay 24VDC 20(NO)/10(NC)A SPDT(26x22x36)mm Plug-In Automotive .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Panasonic Electronic Components
Nº de pieza:
CB1F-24V
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
50
Contact Form:
SPDT (1 Form C)
Relay Construction:
Non-Latching
Max Contact Current:
20A (NO) / 10A (NC)
Coil Voltage:
24 VDC
Coil Current:
75 mA
Coil Resistance:
320 Ohm
Contact Material:
Silver(Cadmium Free)
Must Operate Voltage:
14 VDC
Must Release Voltage:
8.4 VDC
Operate Time:
15 ms
Seal:
Flux Resistant
Mounting:
Connector
Termination Style:
0.25 Quick Connect
Dimension:
26 x 22 x 36 mm
Operating Temperature:
-40 to 85 °C
Packaging:
Carton
The PANASONIC EW/AROMAT part CB1F-24V is a Power Relay specifically designed for automotive applications. This 24VDC relay features a high switching capacity of 20(NO)/10(NC)A and a single pole double throw (SPDT) configuration. With compact dimensions of 26x22x36mm, this plug-in relay is ideal for use in various automotive electrical systems, providing reliable and efficient switching capabilities.
Palabras clave de búsqueda:
CB1F24V
EN STOCK: 850
Puede enviar inmediatamente
Cantidad mínima de pedido:
50
Múltiple:
50
Plazo de entrega de fábrica
24 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
50
$4.96
$248.00
100
$4.79
$479.00
250
$4.52
$1,130.00
500
$4.37
$2,185.00
1.000
$4.22
$4,220.00
2.500
$4.21
$10,525.00
5.000
$4.20
$21,000.00
7.500 +
$4.18
$31,350.00
