CX-412
PANASONIC / SUNXThe CX-412 is a thru-beam type photoelectric sensor with a long sensing range of 15 meters. .. Ver descripción completa
Atributo del producto
Valor del atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
PANASONIC / SUNX
Nº de pieza:
CX-412
RoHS:
Yes
HTS:
853650900
COO:
CN
ECCN:
EAR99
Empaque estándar del proveedor
1
Tipo:
Thru-beam
Distancia de detección máxima:
15 m
Tipo de salida:
NPN
Tiempo de respuesta máximo:
1 ms
Tensión mínima de alimentación de funcionamiento:
12 VDC
Tensión de alimentación de funcionamiento máxima:
24 VDC
Temperatura de Funcionamiento:
-25 to 55 °C
Tipo de Terminal:
Wire Lead
Dimensión:
33.5 x 20 x 11.2 mm
Montaje:
N/A
The CX-412 is a long-range, thru-beam photoelectric sensor from the CX-400 series, designed for reliable object detection. It operates with an infrared LED to achieve a substantial sensing distance of 15 meters and can detect opaque objects with a minimum diameter of 12 mm. This sensor features a fast response time of 1 ms or less, an NPN open-collector output, and switchable Light-ON/Dark-ON operation. Housed in an IP67-rated PBT enclosure, the CX-412 provides robust performance in various industrial environments, making it ideal for applications like package content detection and presence sensing in dusty conditions.
Palabras clave de búsqueda:
CX412
EN STOCK:
45
Puede enviar inmediatamente
Plazo de entrega de fábrica
12 Semanas
Precio (USD)
Cantidad
Precio unitario
Precio total
1
$99.07
$99.07
5
$93.03
$465.15
10
$89.22
$892.20
20
$89.00
$1,780.00
50
$88.77
$4,438.50
100
+
$88.55
$8,855.00
Guías de productos
Accesorios
CN-24-C2
CN-24AL-C2
M8 elbow Connector w/ 2m cablefor all CX-400 series
MS-CX-3
Sensor head - mounting bracket
CN-22-C2
CN-24A-C2
Cable Assembly 2m M8 Circular SKT
MS-RF22
OS-CX-05
Long Sensing Range,Thru-Beam Type Compact Photoelectric Sensor
OS-CX-1X6
SLIT MASK 1MM X 6MM RECT FOR CX | Panasonic Industrial Automation OS-CX-1X6
Los clientes
también compraron
1432797-1
Power Relay 24VDC 360Ohm 35(NO)/20(NC)A SPDT(26.5x26.5x24.5)mm Plug-In Automotive Relay Au...
96.031.4053.1
Conn Circular F 3 POS Screw ST Cable Mount 3 Terminal 1 Port Box
S8VS06024B
Power supply - 60 W - 100-240 VAC input - 24 VDC - 2.5 A output - DIN rail mounting - digi...
OA80AP-22-1WB
