3031416
Phoenix ContactGround modular terminal block - connection method: Spring-cage connection - number of connections: 3 - cross section: 0.08 mm² - 6 mm² - AWG: 28 - 10 - width: 6.2 mm - color: green-yellow - mounting type: NS 35/7,5 - NS 35/15 .. Ver descripción completa
Atributo del producto
Valor de atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Phoenix Contact
Nº de pieza:
3031416
Alias/alias:
ST-4-TWIN-PE
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Paquete estándar del proveedor
50
Body Orientation:
Straight
The PHOENIX CONTACT part 3031416 is a ground modular terminal block that is designed to provide a secure and reliable connection. It features a spring-cage connection method, which ensures easy and efficient installation. With a total of 3 connections available, this terminal block can accommodate various wiring needs. It has a cross-section range of 0.08 mm² - 6 mm², making it suitable for a wide range of wire sizes from AWG 28 to 10. The terminal block has a compact width of 6.2 mm, allowing for efficient use of space. The green-yellow color indicates its grounding functionality. It is designed for mounting on NS 35/7,5 or NS 35/15 DIN rails, providing versatility in installation options.
Palabras clave de búsqueda:
3031416
EN STOCK:
0
A la orden:
300
puede enviar 6/25/26
Cantidad mínima de pedido:
4
Plazo de entrega de fábrica
5 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
4
$7.65
$30.60
25
$7.26
$181.50
50
+
$6.90
$345.00
Guías de productos
FICHA TÉCNICA
Accesorios
DS-ST-4
Cover segment - length: 87 mm - height: 36.5 mm - color: gray
CLIPFIX-35-5
Quick mounting end clamp for NS 35/7,5 DIN rail or NS 35/15 DIN rail - with marking option ...
ATP-ST-TWIN
Partition plate - length: 75.2 mm - width: 2 mm - height: 39 mm - color: gray
D-ST-4-TWIN
End cover - length: 71.5 mm - width: 2.2 mm - height: 29 mm - color: gray
E/UK
End clamp - width: 9.5 mm - height: 35.3 mm - material: PA - length: 50.5 mm - Mounting on ...
E/UK-1
End clamps - for supporting the ends of double-level and three-level terminal blocks - wid ...
FBSR-4-6
Plug-in bridge - pitch: 6.2 mm - number of positions: 4 - color: red
FBSR-5-6
Plug-in bridge - pitch: 6.2 mm - number of positions: 5 - color: red
CLIPFIX-35
Quick mounting end clamp for NS 35/7,5 DIN rail or NS 35/15 DIN rail - with marking option ...
E/NS-35-N
Phoenix Contact DIN Rail End Clamp; E/NS 35 N; for 35mm DIN Rail; Screw Terminal; Gray
FBSR-10-6
Plug-in bridge - pitch: 6.2 mm - number of positions: 10 - color: red
FBSR-2-6
Plug-in bridge - pitch: 6.2 mm - number of positions: 2 - color: red
ST-BW
Actuation tool - for all 2.5 mm² - 4.0 mm² spring-cages
RPS
Reducing plug - color: gray
ST-IL
Operating decal for the ST terminal block
ZB 6,LGS:GLEICHE ZAHLEN
Zack marker strip, Strip, white, labeled, can be labeled with: CMS-P1-PLOTTER, Printed hor ...
UCT-TMF-6
The 0828746 is an unlabeled sheet marker designed to snap into the flat marker groove of t ...
UCT-TM-6
Marker for terminal blocks - Sheet - white - unlabeled - can be labeled with: TOPMARK NEO ...
UC-TMF-6
Connector Accessories Terminal Block Marker Straight Polyamide White
UC-TM-6
Terminal Block Marker - White - Blank - Printable - For 6.2mm W TB - 80/Sht
FBSR-3-6
Plug-in bridge - pitch: 6.2 mm - number of positions: 3 - color: red
NS-35/15-CAP
DIN rail end piece - for DIN rail NS 35/15
ZBF-6:UNBEDRUCKT
Zack Marker strip - flat - Strip - white - unlabeled - can be labeled with: PLOTMARK - CMS ...
ZB-6-CUS
Zack marker strip - can be ordered: Strip - white - labeled according to customer specific ...
UC-TM-6-CUS
Marker for terminal blocks - can be ordered: by sheet - white - labeled according to custo ...
NS-35/15-WH-PERF-2000MM
Connector Accessories DIN Rail Straight Steel White
NS-35/15-ZN-UNPERF-2000MM
DIN Rail - 35mmx15mm - Unslotted - Steel 2m
NS-35/15-ZN-PERF-2000MM
DIN Rail - 35mmx15mm - Slotted - 2m
ZB-6:UNBEDRUCKT
Zack marker strip - Strip - white - unlabeled - can be labeled with: PLOTMARK - CMS-P1-PLO ...
ZBF-6-CUS
Zack Marker strip - flat - Strip - can be ordered: Strip - white - labeled according to cu ...
UC-TMF-6-CUS
Marker for terminal blocks - can be ordered: by sheet - white - labeled according to custo ...
NS-35/15-PERF-2000MM
DIN Rail - 35mmx15mm - Slotted - 2m
NS-35/15-UNPERF-2000MM
The 1201714 is an unperforated, standard profile DIN rail made of galvanized steel, measur ...
NS-35/15-AL-UNPERF-2000MM
DIN Rail - 35mmx15mm - Unslotted - Aluminum - 2m
