D2475
Sensata / CrydomSolid-State Relay - Control Voltage 3-32 VDC - Max Input Current 12 mA - Output 24-280 VAC - Max Load Current 75 A - 4 Pins - 1 Form A - Screw Termination .. Ver descripción completa
Atributo del producto
Valor de atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Sensata / Crydom
Nº de pieza:
D2475
RoHS:
Yes
HTS:
8536490080
COO:
MX
ECCN:
EAR99
Paquete estándar del proveedor
20
Output Type:
AC
Maximum Output Voltage:
280(RMS) V
Maximum Output Current:
75(RMS) A
Output Device:
SCR
Input Type:
DC
Input Voltage:
32 V
Mounting:
Screw
Circuit Arrangement:
1 Form A
Dimension:
58.4 x 45.7 x 23 mm
The D2475 is a solid-state relay series 1 with SCR output for heavy industrial loads. Input control voltage range is 3-32 VDC. Operating voltage is 24-280 VAC and the max load current is 75 A. Series 1 relay has redesigned housing with anti-rotation barriers. I/O isolation voltage is 4000 Vrms. Switching type: zero voltage turn-on. Mounting type: panel mount.
Palabras clave de búsqueda:
D2475
EN STOCK:
244
Puede enviar inmediatamente
A la orden:
300
puede enviar 7/2/26
Plazo de entrega de fábrica
12 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
1
$80.47
$80.47
5
$78.75
$393.75
10
$77.20
$772.00
20
$76.42
$1,528.40
60
$75.66
$4,539.60
100
+
$74.72
$7,472.00
Guías de productos
CAD Drawing
FICHA TÉCNICA
Selecting a SSR
Component360: Sensata-Crydom Sensata Series 1 SSR
Learn more about Sensata | Crydom Panel Mount Solid State Relays - Series 1
Product Changes
