MSP103C04
TE Connectivity / Alcoswitch BrandPushbutton Switch - SPST-NO - Off-Mom - 3A, 125VAC - Plunger for Cap Actuator - No Marking - Red Cap - Solder Lug - Panel Mount, Rear. .. Ver descripción completa
Atributo del producto
Valor de atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
TE Connectivity / Alcoswitch Brand
Nº de pieza:
MSP103C04
Alias/alias:
1825516-2
RoHS:
Yes
HTS:
8536509033
COO:
CN
ECCN:
EAR99
Paquete estándar del proveedor
100
Tipo de paquete:
Pack
Mounting:
Panel Mount
Pole Throw Configuration:
SPST
Bushing Type:
Threaded
Switch Configuration:
N.O.
Contact Rating @ Voltage:
3A@125 VAC
Actuator Style:
Round Plunger
Illumination:
N/R
Terminal Type:
Solder
Body Orientation:
Straight
Dimension:
11.9 x 11.9 x 26.4 mm
The MSP103C04 is a high-quality momentary push button switch from the TE Connectivity / Alcoswitch Brand. This switch is designed with a single-pole, single-throw (SPST) configuration, making it perfect for applications that require a normally open (N.O.) contact. Its round plunger allows for easy and comfortable operation, while its 3A current rating and 125VAC voltage rating make it suitable for a wide range of low-power electrical circuits. The switch is panel mountable using wire lugs, ensuring a secure connection and easy installation. Offered as a loose piece, it provides flexibility for custom applications.
Características destacadas del producto:
- Switch - Mechanical
- Not Tactile
- Single Pole - Single Throw Configuration (Pole-Throw)
- Contact Rating = 3A
- Operating Function = Normally Open, Momentary
Palabras clave de búsqueda:
MSP103C04
EN STOCK:
158
Puede enviar inmediatamente
A la orden:
500
puede enviar 6/24/26
Cantidad mínima de pedido:
5
Plazo de entrega de fábrica
29 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
5
$5.58
$27.90
25
$3.76
$94.00
100
$3.62
$362.00
300
$3.55
$1,065.00
500
$3.54
$1,770.00
1.000
$3.53
$3,530.00
2.500
$3.52
$8,800.00
5.000
+
$3.51
$17,550.00
