1-104480-4 by te connectivity / amp brand
Imagen de referencia - consulte las especificaciones del fabricante
FICHA TÉCNICA

1-104480-4

TE Connectivity / AMP Brand

SHORT POINT RECP CONT LP .. Ver descripción completa

Cumple con RoHS
BAG embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantía del certificado de conformidad
Atributo del producto
Valor del atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
TE Connectivity / AMP Brand
Nº de pieza:
1-104480-4
RoHS:
Yes
HTS:
8538908140
COO:
MX
ECCN:
EAR99
Empaque estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precio y disponibilidad.
1000
Tipo de encapsulado:
BAG
Tipo de contacto:
Stamped Signal
Género:
SKT
Tamaño del contacto:
N/A
Calibre del Cable:
22-26 AWG
Material de Contacto:
Copper Alloy
Recubrimiento del Contacto:
Tin over Nickel
Corriente Nominal Máxima:
3 A
Método de terminación:
Crimp
1-104480-4 is a crimp snap-in short point replacement contact designed for the AMPMODU MTE interconnect system. This contact features matte tin plating and is compatible with wire gauges in the 22–26 AWG range, supporting crimp-based assembly methods for flexible wire termination. The contact is rated for a maximum current of 3 amps in free air and operates reliably across a temperature range of -65°C to +105°C. It is supplied as a loose piece and mates with standard MTE receptacle housings and headers, making it suitable for wire-to-board and wire-to-wire applications. Common uses include medical instruments, automotive controls, computers, telecommunications equipment, and industrial appliances where reliable, cost-effective interconnection is required.
Características destacadas:
  • Contact
  • Contact Type = Receptacle
  • Terminate To Wire
  • Wire Insulation Diameter = .64 - 1.52 mm
  • Wire Range = 0.12-0.40² [26-22] mm [AWG]
Palabras clave de búsqueda:
11044804
EN STOCK: 4.763
Puede enviar inmediatamente
MOQ para Cantidad en Stock:
100
MOQ para cantidad agotada:
12500
Plazo de entrega de fábrica
11 Semanas
Precio (USD)
Cantidad
Precio unitario
Precio total
100
$0.4829
$48.2900
2.500
$0.4816
$1,204.0000
5.000
$0.4804
$2,402.0000
7.500
$0.4792
$3,594.0000
12.500
$0.4780
$5,975.0000
25.000
$0.2523
$6,307.5000
37.500
$0.1735
$6,506.2500
50.000 +
$0.1700
$8,500.0000
