1-353293-2 by te connectivity / amp brand
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

1-353293-2

TE Connectivity / AMP Brand

MINI CT MT REC ASSY 12P GRAY .. Ver descripción completa

Cumple con RoHS
Bag embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
TE Connectivity / AMP Brand
Nº de pieza:
1-353293-2
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
1000
Tipo de paquete:
Bag
Type:
IDC Connector
Body Orientation:
Straight
Gender:
RCP
Mounting:
Cable Mount
Pitch:
1.5 mm
Number of Contacts:
12
Maximum Voltage Rating:
50,50 VDC|VAC
Maximum Current Rating:
2/Contact A
Termination Method:
IDT
Operating Temperature:
-30 to 105 °C
1-353293-2 is a 12-position mass termination (MT) receptacle housing from TE Connectivity's AMP Mini CT connector series, designed for wire-to-board and wire-to-wire interconnect applications. This miniature connector features a 1.5 mm pitch with preloaded IDC contacts and supports 26-28 AWG wire gauges. The housing is rated for 50 V AC with an operating current of 2 A at 26 AWG and operates within a temperature range of -65°C to 105°C. It mates with various single row post header assemblies including thru-hole and SMT mounting styles. Common applications include business equipment, industrial machines, IoT/smart devices, and PC peripherals where compact, reliable discrete wire interconnects are required.
Características destacadas del producto:
  • Receptacle Assembly
  • Connector Type = MT (Mass Termination)
  • Number of Positions = 12
  • Without Panel Attachment
  • Terminate To Wire
Palabras clave de búsqueda:
13532932
EN STOCK: 0
Cantidad mínima de pedido:
100
Plazo de entrega de fábrica
5 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
100
$0.3142
$31.4200
500
$0.2811
$140.5500
1.000
$0.2804
$280.4000
3.000
$0.2688
$806.4000
5.000
$0.2634
$1,317.0000
8.000
$0.2628
$2,102.4000
15.000
$0.2600
$3,900.0000
25.000 +
$0.2148
$5,370.0000
