796634-3
TE Connectivity / AMP Brand3 Position Terminal Block Plug, Female Sockets 0.200" (5.08mm) 180° Free Hanging (In-Line) .. Ver descripción completa
Atributo del producto
Valor del atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
TE Connectivity / AMP Brand
Nº de pieza:
796634-3
RoHS:
Yes
HTS:
8536904000
COO:
IT
ECCN:
EAR99
Embalaje estándar del proveedor
200
Tipo de encapsulado:
BOX
Tipo:
Eurostyle Block
Montaje:
Cable Mount
Género:
F
Método de terminación:
Screw
Paso:
5.08 mm
Número de circuitos:
3
Tensión Máxima Nominal:
300 VAC
Corriente Nominal Máxima:
15/Contact A
Calibre del Cable:
12-30 AWG
Temperatura de Funcionamiento:
N/A
The 796634-3 is a 3-position 1 row 5.08mm pluggable Terminal Block with tin-plated phosphor bronze contact, nickel-plated brass screw, polyamide 6.6 green housing. Plug connector, right angle mounting, through hole contact mount, screw wire connection method, M3 screw and 30 to 16AWG wire range.
Side wire entry angle Number of Positions: 3 Position
Pitch: 5.08 mm
Connection Method: Screw
Current Rating: 15 A
Voltage Rating: 300 V
Wire Gauge Range: 30 AWG to 12 AWG
Color: Green
Contact Plating: Tin
Housing Material: Polyamide (PA)
Mounting Angle: Right
Applications
Industrial
Características destacadas:
- Connector
- Connector Type = Plug
- Housing Color = Green
- Not Stacked
- Without Threaded Flange
Palabras clave de búsqueda:
7966343
EN STOCK:
22.363
Puede enviar inmediatamente
Cantidad mínima de pedido:
10
Plazo de entrega de fábrica
12 Semanas
Precio (USD)
Cantidad
Precio unitario
Precio total
10
$2.108
$21.080
50
$1.440
$72.000
200
$1.214
$242.800
400
$1.153
$461.200
600
$1.117
$670.200
1.000
$1.034
$1,034.000
2.600
$1.032
$2,683.200
5.000
+
$0.771
$3,855.000
