298-10-01100
TE Connectivity / Elcon BrandConn Housing RCP 4/21 POS Crimp ST Cable Mount .. Ver descripción completa
Atributo del producto
Valor del atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
TE Connectivity / Elcon Brand
Nº de pieza:
298-10-01100
Alias/también conocido como:
1648208-1
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Empaque estándar del proveedor
45
Tipo de encapsulado:
BOX
Montaje:
N/A
Orientación del Cuerpo:
Straight
Género:
SKT
Número de Contactos:
4/21
Tensión Máxima Nominal:
N/A
Corriente Nominal Máxima:
35/Contact A
Temperatura de Funcionamiento:
N/A
The 1648208-1 is a Lower Drawer Connector Socket Housing from the AMP & ELCON Power Connector series. This housing is designed to accommodate a mix of contact sizes, including size #16, #20, and #12, with specific cavities designated for #16 contacts and others for #12 or #12 Hot Plug contacts. It supports both float and fixed mounting configurations, providing flexibility in system design. The housing is used with separately ordered socket contacts which are available in various termination styles such as Crimp, Compliant Press-fit, and PCB Tail. This customizable configuration makes it suitable for power distribution applications in drawer systems where different power and signal requirements need to be met within a single connector.
Características destacadas:
- Housing
- Contact Size = 12, 16, 20
- Drawer Style = Lower
- Socket
- Size 12 + Size 20 + Size 16 Contact Configuration
Palabras clave de búsqueda:
2981001100
EN STOCK:
0
Cantidad mínima de pedido:
15
Plazo de entrega de fábrica
8 Semanas
Precio (USD)
Cantidad
Precio unitario
Precio total
15
$13.25
$198.75
45
$11.46
$515.70
90
$11.14
$1,002.60
135
$10.53
$1,421.55
270
$10.50
$2,835.00
540
$9.62
$5,194.80
1.035
+
$8.76
$9,066.60
