57.404.6955.1 by wieland electric
Imagen de referencia - consulte las especificaciones del fabricante
FICHA TÉCNICA

57.404.6955.1

Wieland Electric

A three-tier installation terminal block with screw connections, providing two line feed-throughs and one ground (PE) connection for electrical distribution systems. .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Descontinuado
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantía del certificado de conformidad
Atributo del producto
Valor del atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Wieland Electric
Nº de pieza:
57.404.6955.1
RoHS:
Yes
HTS:
85369010
COO:
DE
ECCN:
EAR99
Embalaje estándar del proveedor La cantidad de artículos, la longitud, el peso o el volumen contenidos en el embalaje original del proveedor para facilitar un almacenamiento, una manipulación y una distribución eficientes.
100
Orientación del Cuerpo:
Straight
Ciclo de vida:
Descontinuado
The 57.404.6955.1 is a three-tier installation terminal block from the selos BIT series, designed for high-density wiring in electrical distribution systems. It features screw connections that accept solid conductors from 0.5 to 6 mm² and fine-stranded conductors from 0.5 to 4 mm² (22-10 AWG). This block is rated for 400V and 26A according to VDE standards, and 300V for UL/CSA applications, all within a compact 6 mm width. The configuration provides two line feed-through connections and one ground (PE) connection that interfaces directly with the DIN rail. It is ideal for use in junction boxes and distribution panels where space is limited and reliable connections are critical.
Palabras clave de búsqueda:
5740469551
  Este producto está descontinuado, pero aún está en stock
EN STOCK: 395
Puede enviar inmediatamente
Cantidad mínima de pedido:
5
Precio (USD)
Cantidad
Precio unitario
Precio total
5
$7.08
$35.40
25
$5.94
$148.50
100
$5.50
$550.00
300
$5.05
$1,515.00
500
$5.03
$2,515.00
1.000
$4.91
$4,910.00
2.500
$4.78
$11,950.00
5.000 +
$4.72
$23,600.00
