NC3FD-V
NEUTRIKD Series - 3 pole female receptacle, vertical PCB mount - Nickel housing - silver contacts Universal D-size metal body XLR panel mount series for pcb mount applications. Insert is removable from shell for ease assembling. UL recognized component. .. Ver descripción completa
Atributo del producto
Valor del atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
NEUTRIK
Nº de pieza:
NC3FD-V
RoHS:
Yes
HTS:
8536694040
COO:
HU
ECCN:
EAR99
Empaque estándar del proveedor
100
Tipo:
XLR Connector
Género:
F
Orientación del Cuerpo:
Straight
Montaje:
Through Hole
Material de la Carcasa:
Zinc Die Cast
Número de Contactos:
3
Recubrimiento del Contacto:
Silver over Nickel
Método de terminación:
Solder
Temperatura de Funcionamiento:
-30 to 80 °C
The NC3FD-V is 3 pole female receptacle, vertical PCB mount, Nickel housing, silver contacts The NC3FD-V has rated voltage of < 50 V and rated current per contact of 6 A and dielectric strength of 1,5 kVdc . Universal D-size metal body XLR panel mount series for pcb mount applications. Insert is removable from shell for ease assembling. UL recognized component.
Características destacadas:
- D-shape metal shell
- Optimal RF protection using 3 shield contacts.
- Insert is removable from rear of connector and locked into place by internal latch - permitting assembling and testing of pcb before assembling into housing
- Front or rear panel mount
Palabras clave de búsqueda:
NC3FDV
EN STOCK:
545
Puede enviar inmediatamente
Cantidad mínima de pedido:
5
Plazo de entrega de fábrica
3 Semanas
Precio (USD)
Cantidad
Precio unitario
Precio total
5
$13.25
$66.25
25
$7.15
$178.75
50
$6.74
$337.00
100
$6.35
$635.00
300
$5.88
$1,764.00
500
$5.67
$2,835.00
1.000
$5.40
$5,400.00
2.500
+
$5.39
$13,475.00
Hoja de datos
Learn more about Neutrik's Best Sellers for the A/V and Lighting Industry
