AQG22124 by panasonic electronic components
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

AQG22124

Panasonic Electronic Components

The AQG22124 is a slim, zero-cross solid state relay (SSR) featuring a 2A maximum load current and a 24V DC rated control voltage. .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Panasonic Electronic Components
Nº de pieza:
AQG22124
RoHS:
Yes
HTS:
8541498000
COO:
JP
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
20
Output Type:
AC
Maximum Output Voltage:
264 V
Maximum Output Current:
2 A
Output Device:
N/A
Input Type:
DC
Input Voltage:
28.8 V
Mounting:
Through Hole
Circuit Arrangement:
N/A
Dimension:
24.5(Max) x 4.5(Max) x 20.5(Max) mm
The AQG22124 is a zero-cross solid state relay designed for 2A load control applications. It operates with a DC control voltage range of 19.2V to 28.8V and switches AC load voltages from 75Vrms to 264Vrms. This SSR features a high dielectric strength of 3,000Vrms between the input and output, a maximum ON-state voltage drop of 1.6V, and a built-in snubber circuit to prevent malfunction from noise. Its slim profile and robust specifications make it ideal for use in household appliances, industrial machinery, healthcare equipment, and microcomputer boards.
Palabras clave de búsqueda:
AQG22124
EN STOCK: 200
Puede enviar inmediatamente
Cantidad mínima de pedido:
20
Múltiple:
20
Plazo de entrega de fábrica
14 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
20
$4.01
$80.20
60
$3.85
$231.00
100
$3.72
$372.00
260
$3.52
$915.20
500
$3.39
$1,695.00
1.000
$3.27
$3,270.00
2.500
$3.26
$8,150.00
5.000 +
$3.25
$16,250.00
